A: Heat Pump Width = 1309mm
B: Heat Pump Height = 700mm
C: Heat Pump Depth = 400mm
D: Heat Pump Height (total) = 717mm
E: Heat Pump Depth (total) = 426mm
F: 121mm
G: 644mm
H: 379mm
Media Content Block
Product Literature
Installation and Service Manuals
User Guides
Specification Guides
Energy Labels
Warranty Guide
Dimensions
4-5kW models
Dimensions
7-13kW models
A: Heat Pump Width = 1388mm
B: Heat Pump Height = 850mm
C: Heat Pump Depth = 448mm
D: Heat Pump Height (total) = 864mm
E: Heat Pump Depth (total) = 523mm
F: 191mm
G: 656mm
H: 363mm
